Yutong 8.9M City Bus – Redefining Urban Travel
Compact, Efficient, and Built for the Modern City
The Yutong 8.9M City Bus combines state-of-the-art technology and modern design,
offering a compact solution for urban commuting. Designed for comfort, reliability, and efficiency,
the Yutong 8.9M is the ultimate choice for navigating busy city streets.
Up to 70 km/h with Euro 5 engine –
Environmentally friendly and built for the future.
Stylish & Durable Design
Constructed with galvanized full-steel, electro-coated for an 8-year anti-corrosion guarantee, the Yutong 8.9M City Bus combines style with durability.
Passenger Comfort
With 21 seats and a designated wheelchair area, abrasion-resistant flooring, and a pneumatic inner swing door for easy boarding, this bus ensures a comfortable journey for every passenger.
Engine & Transmission
Powered by a 147 kW Euro 5 engine, the Yutong 8.9M bus features a VOITH automatic transmission with a retarder for smooth and efficient driving.
Advanced Safety Features
Safety is prioritized with dual-circuit pneumatic brakes, disc brakes, and WABCO ABS. The bus also includes 6 cameras for full surveillance and a 500 GB recording system.
Eco-Friendly Interior
Built with flame-retardant, environmentally friendly materials, the Yutong 8.9M meets strict German environmental control standards.
Technology
Equipped with a 19” foldable LCD screen, SD card player, USB ports, and wireless microphone, the bus offers passengers a connected and enjoyable journey.
70 km/h
Max Speed
21 + 1 wheelchair area
Seating
400 km (urban conditions)
Operating Range
YC4G200-50 (Euro 5)
Engine
Dimensions
8940mm (L) x 2420mm (W) x 3140mm (H)
Technical Highlights
Detail technical highlight
| SPECIFICATION | |
|---|---|
| OVERALL DIMENSION | |
| Model | ZK6890HG |
| Engine Position | Rear |
| Overall Dimension (mm) | 8940 x 2420 x 3140 |
| Wheelbase (mm) | 4350 |
| Front / Rear Track Width (mm) | 2000 / 1844 |
| Front & Rear Overhang (mm) | 2000 / 2590 |
| Kerb Weight (kg) | 9100 |
| Max. Total Mass | 13300 |
| Max. Speed (km/h) | 70 |
| App. / Dep. Angle (°) | 10/8 |
| Fuel Tank Capacity (L) | 160 |
| ELECTRICAL & AC | |
| Batteries | 24V , 2 pieces 150Ah |
| A/C | YUTONG roof-mounted 24000kcal/h , BOCK compressor |
| Defrosting | Natural Air |
| CHASSIS SPECIFICATION | |
| Engine | YC4G200-50 (Euro 5), 147kw/2200rpm , 5.2L, 720N.m/1100~1500rpm |
| Transmission | VOITH D854.6S With Retarder |
| Front Axle | YUTONG, Disc Brake |
| Rear Axle | YUTONG, Disc Brake |
| Suspension | Air-suspension, F2/R4, Stabilizer Bar F/R, Dual Shock Absorber |
| Brake System | Dual-circuit Pneumatic Brake, Disc F/Disc R, WABCO Air Dryer, WABCO ABS |
| Steering System | RHD, Intergrated Adjustable Power Steering |
| Tyre | 265/70R19.5 |
| Wheel Cover | Stainless, 4pcs |
| BODY CONFIGURATION | |
| Material | Galvanized Full Steel, Electro-coated |
| Emergency Door | STD |
| Passenger Door |
Pneumatic Inner Swing Single Leaf Door in the Front Pneumatic Inner Swing Double Leaf Door in the Middle |
| Floor Structure | Flat , Abrasion-resistant ooring |
| Driver Seat | Mechanical Shock Absorption with 3-Point Safety Belt |
| Passenger Seat | 21+1 wheelchair area |
| Windshield | F : 1 Piece, Laminated Glass ; R : Steel Panel without Glass |
| Side Window | Full-sealed Tempered SafetyGlass, 70% Transparency |
| Rear-view Mirror | Electric Rear-view Mirror |
| CCTV & Audiovisual System | SD Card Player + USB + Wireless Microphone, Middle 19” foldable LCD, 6 ways camera + 500G recordable |
| Interior Trimming | Retractable dual-semi visor, Soft Cloth or Plastic Side window curtain, Manual Inner-view mirror including, Date/Time/Tempreture |
| Roof Hatch | 2 Sets with Ventilator |
| Extinguishing Equipment | 2 Pieces in engine compartment |
| OTHERS | |
| Electro-coating | 8 years Anti-corrosion/rust (No damage) |
| Wiring & Connector | Tin-plated ame retardant copper wiring, Water-proof |
| Material Standard | Flame-retardant & Environmental friendly interior, German environmental control standard (VDA standard) |
